Cal 2 27
The Cal 2 27 is a 26.58ft masthead sloop designed by William Lapworth and built in fiberglass by Jensen Marine/Cal Boats between 1974 and 1980.
656 units have been built.
The Cal 2 27 is a moderate weight sailboat which is a reasonably good performer. It is very stable / stiff and has a good righting capability if capsized. It is best suited as a coastal cruiser. The fuel capacity is originally small. There is a very short water supply range.
Cal 2 27 for sale elsewhere on the web:
Main features
| Model | Cal 2 27 | ||
| Length | 26.58 ft | ||
| Beam | 9.25 ft | ||
| Draft | 4.25 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
Login or register to personnalize this screen.
You will be able to pin external links of your choice.
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 16.92 | ||
| Ballast / displ. | 46.27 % | ||
| Displ. / length | 277.86 | ||
| Comfort ratio | 22.83 | ||
| Capsize | 1.97 |
Hull
| Hull type | Monohull fin keel with spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 22.08 ft | ||
| Maximum draft | 4.25 ft | ||
| Displacement | 6700 lbs | ||
| Ballast | 3100 lbs | ||
| Hull speed | 6.30 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 375 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 216 sq.ft | ||
| Sail area main | 158.62 sq.ft | ||
| I | 36 ft | ||
| J | 12 ft | ||
| P | 30.80 ft | ||
| E | 10.30 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 25 gals |
Accommodations
| Water capacity | 20 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Jensen Marine/Cal Boats | ||
| Designer | William Lapworth | ||
| First built | 1974 | ||
| Last built | 1980 | ||
| Number built | 656 |
Other photos
