Cal 2 25
The Cal 2 25 is a 25.25ft masthead sloop designed by C. William Lapworth and built in fiberglass by Jensen Marine/Cal Boats between 1977 and 1983.
392 units have been built.
The Cal 2 25 is a light sailboat which is a good performer. It is very stable / stiff and has a low righting capability if capsized. It is best suited as a day-boat. There is a very short water supply range.
Cal 2 25 for sale elsewhere on the web:
Main features
| Model | Cal 2 25 | ||
| Length | 25.25 ft | ||
| Beam | 9 ft | ||
| Draft | 4.50 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
Login or register to personnalize this screen.
You will be able to pin external links of your choice.
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 18.51 | ||
| Ballast / displ. | 44.44 % | ||
| Displ. / length | 188.67 | ||
| Comfort ratio | 16.21 | ||
| Capsize | 2.18 |
Hull
| Hull type | Monohull fin keel with spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 22 ft | ||
| Maximum draft | 4.50 ft | ||
| Displacement | 4500 lbs | ||
| Ballast | 2000 lbs | ||
| Hull speed | 6.29 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 314 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 181.50 sq.ft | ||
| Sail area main | 133 sq.ft | ||
| I | 33 ft | ||
| J | 11 ft | ||
| P | 28 ft | ||
| E | 9.50 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 21 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Jensen Marine/Cal Boats | ||
| Designer | C. William Lapworth | ||
| First built | 1977 | ||
| Last built | 1983 | ||
| Number built | 392 |
