The C&C 34r is a 34.08ft masthead sloop designed by Robert Ball and built in fiberglass by C&C Yachts since 1989.
The C&C 34r is a light sailboat which is a high performer. It is stable / stiff and has a low righting capability if capsized. It is best suited as a fast cruiser. The fuel capacity is originally small. There is a short water supply range.
Main features
| Model | C&C 34r | ||
| Length | 34.08 ft | ||
| Beam | 11.58 ft | ||
| Draft | 7.42 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 20.49 | ||
| Ballast / displ. | 39.17 % | ||
| Displ. / length | 187.34 | ||
| Comfort ratio | 22.46 | ||
| Capsize | 2.03 |
Hull
| Hull type | Monohull fin keel with bulb and spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 30.58 ft | ||
| Maximum draft | 7.42 ft | ||
| Displacement | 12000 lbs | ||
| Ballast | 4700 lbs | ||
| Hull speed | 7.41 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 669 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 360.89 sq.ft | ||
| Sail area main | 308.13 sq.ft | ||
| I | 48.67 ft | ||
| J | 14.83 ft | ||
| P | 42.50 ft | ||
| E | 14.50 ft |
Engine
| Nb engines | 1 | ||
| Total power | 30 HP | ||
| Fuel capacity | 40 gals |
Accommodations
| Water capacity | 60 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | C&C Yachts | ||
| Designer | Robert Ball | ||
| First built | 1989 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
