The Carol Ketch is a 36.65ft masthead ketch designed by John G. Hanna and built in wood by Many builders since 1974.
It accomodates 7 people in 2 cabins plus salon.
The Carol Ketch is a moderate weight sailboat which is under powered. It is reasonably stable / stiff and has an excellent righting capability if capsized. It is best suited as a heavy bluewater cruising boat. The fuel capacity is average. There is a good water supply range.
Main features
| Model | Carol Ketch | ||
| Length | 36.65 ft | ||
| Beam | 11.98 ft | ||
| Draft | 4.92 ft | ||
| Country | Worldwide | ||
| Estimated price | $ 73200 |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 13.39 | ||
| Ballast / displ. | 28.33 % | ||
| Displ. / length | 269.18 | ||
| Comfort ratio | 41.95 | ||
| Capsize | 1.61 |
Hull
| Hull type | Monohull double-ended with long keel | ||
| Construction | Wood | ||
| Waterline length | 35.27 ft | ||
| Maximum draft | 4.92 ft | ||
| Displacement | 26455.44 lbs | ||
| Ballast | 7495.71 lbs | ||
| Hull speed | 7.96 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Ketch | ||
| Sail area (100%) | 742.71 sq.ft | ||
| Air draft | 49.21 ft | ||
| Sail area fore | 0 sq.ft | ?? | |
| Sail area main | 0 sq.ft | ?? | |
| I | 0 ft | ?? | |
| J | 0 ft | ?? | |
| P | 0 ft | ?? | |
| E | 0 ft | ?? |
Engine
| Nb engines | 1 | ||
| Total power | 75 HP | ||
| Fuel capacity | 84.54 gals |
Accommodations
| Water capacity | 105.67 gals | ||
| Headroom | 6.23 ft | ||
| Nb of cabins | 2 | ||
| Nb of berths | 7 | ||
| Nb heads | 1 |
Builder data
| Builder | Many builders | ||
| Designer | John G. Hanna | ||
| First built | 1974 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
