The Catana 59 is a 58.7ft fractional sloop designed by Chantier Catana and built in fiberglass sandwich e-glass by Catana (FRA) since 2012.
It accomodates 10 people in 4 cabins plus salon.
The Catana 59 is an ultralight sailboat which is a very high performer. The fuel capacity is excellent. There is an excellent water supply range.
Main features
| Model | Catana 59 | ||
| Length | 58.70 ft | ||
| Beam | 31.13 ft | ||
| Draft | 5.12 ft | ||
| Country | France (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 28.23 | ||
| Ballast / displ. | 0 % | ||
| Displ. / length | 91.97 | ||
| Comfort ratio | 11.28 | ||
| Capsize | 3.59 |
Hull
| Hull type | Catamaran twin daggerboard | ||
| Construction | Fiberglass sandwich E-Glass | ||
| Waterline length | 58.70 ft | ||
| Maximum draft | 12.30 ft | ||
| Displacement | 41667 lbs | ||
| Ballast | 0 lbs | ||
| Hull speed | 10.27 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 2120 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 861.11 sq.ft | ||
| Sail area main | 1237.85 sq.ft | ||
| I | 0 ft | ?? | |
| J | 0 ft | ?? | |
| P | 0 ft | ?? | |
| E | 0 ft | ?? |
Engine
| Nb engines | 2 | ||
| Total power | 220 HP | ||
| Fuel capacity | 211.34 gals |
Accommodations
| Water capacity | 211.34 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 4 | ||
| Nb of berths | 10 | ||
| Nb heads | 4 |
Builder data
| Builder | Catana (FRA) | ||
| Designer | Chantier Catana | ||
| First built | 2012 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
