The Yamaha 35cs is a 35.24ft masthead sloop designed by Yamaha and built in fiberglass by Yamaha since 1980.
It accomodates 6 people in 2 cabins plus salon.
The Yamaha 35cs is a heavy sailboat which is under powered. It is very stable / stiff and has a good righting capability if capsized. It is best suited as a coastal cruiser. The fuel capacity is average. There is a short water supply range.
Main features
| Model | Yamaha 35cs | ||
| Length | 35.24 ft | ||
| Beam | 10.99 ft | ||
| Draft | 4.59 ft | ||
| Country | Japan (Asia) | ||
| Estimated price | $ 31320 |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 13.37 | ||
| Ballast / displ. | 42.62 % | ||
| Displ. / length | 331.96 | ||
| Comfort ratio | 29.45 | ||
| Capsize | 1.85 |
Hull
| Hull type | Monohull fin keel with rudder on skeg | ||
| Construction | Fiberglass | ||
| Waterline length | 26.25 ft | ||
| Maximum draft | 4.59 ft | ||
| Displacement | 13448.18 lbs | ||
| Ballast | 5732.01 lbs | ||
| Hull speed | 6.87 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 471.03 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 290.52 sq.ft | ||
| Sail area main | 180.40 sq.ft | ||
| I | 39.01 ft | ||
| J | 14.90 ft | ||
| P | 32.81 ft | ||
| E | 10.99 ft |
Engine
| Nb engines | 1 | ||
| Total power | 30 HP | ||
| Fuel capacity | 52 gals |
Accommodations
| Water capacity | 58 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 2 | ||
| Nb of berths | 6 | ||
| Nb heads | 2 |
Builder data
| Builder | Yamaha | ||
| Designer | Yamaha | ||
| First built | 1980 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
