The Yamaha 33 is a 33.33ft masthead sloop designed by Yamaha/Norlin and built in fiberglass by Yamaha since 1976.
The Yamaha 33 is a moderate weight sailboat which is a good performer. It is very stable / stiff and has a low righting capability if capsized. It is best suited as a coastal cruiser. The fuel capacity is originally very small. There is a short water supply range.
Main features
| Model | Yamaha 33 | ||
| Length | 33.33 ft | ||
| Beam | 11 ft | ||
| Draft | 6.25 ft | ||
| Country | Japan (Asia) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 18.88 | ||
| Ballast / displ. | 45.45 % | ||
| Displ. / length | 221.97 | ||
| Comfort ratio | 21.32 | ||
| Capsize | 2.07 |
Hull
| Hull type | Monohull fin keel with rudder on skeg | ||
| Construction | Fiberglass | ||
| Waterline length | 26.92 ft | ||
| Maximum draft | 6.25 ft | ||
| Displacement | 9700 lbs | ||
| Ballast | 4409 lbs | ||
| Hull speed | 6.95 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 535 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 310.50 sq.ft | ||
| Sail area main | 224.31 sq.ft | ||
| I | 45 ft | ||
| J | 13.80 ft | ||
| P | 39.70 ft | ||
| E | 11.30 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 18 gals |
Accommodations
| Water capacity | 45 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Yamaha | ||
| Designer | Yamaha/Norlin | ||
| First built | 1976 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
