The Yamaha 29 is a 28.54ft masthead sloop designed by Groupe Finot and built in fiberglass by Yamaha since 1975.
55 units have been built.
The Yamaha 29 is a moderate weight sailboat which is a reasonably good performer. It is stable / stiff and has a low righting capability if capsized. It is best suited as a day-boat.
Main features
| Model | Yamaha 29 | ||
| Length | 28.54 ft | ||
| Beam | 10.01 ft | ||
| Draft | 4.92 ft | ||
| Country | Japan (Asia) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 16.54 | ||
| Ballast / displ. | 35.87 % | ||
| Displ. / length | 249.23 | ||
| Comfort ratio | 18.88 | ||
| Capsize | 2.16 |
Hull
| Hull type | Monohull fin keel with rudder on skeg | ||
| Construction | Fiberglass | ||
| Waterline length | 22.54 ft | ||
| Maximum draft | 4.92 ft | ||
| Displacement | 6393 lbs | ||
| Ballast | 2293 lbs | ||
| Hull speed | 6.36 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 355 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 193.90 sq.ft | ||
| Sail area main | 160.73 sq.ft | ||
| I | 34.78 ft | ||
| J | 11.15 ft | ||
| P | 29.33 ft | ||
| E | 10.96 ft |
Engine
| Nb engines | 1 | ||
| Total power | 12 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Yamaha | ||
| Designer | Groupe Finot | ||
| First built | 1975 | ||
| Last built | 0 | ?? | |
| Number built | 55 |
