The Yamaha 28 is a 28.0ft masthead sloop designed by Yamaha Design team and built in fiberglass by Yamaha since 1980.
The Yamaha 28 is a moderate weight sailboat which is a good performer. It is reasonably stable / stiff and has a low righting capability if capsized. It is best suited as a day-boat. The fuel capacity is originally very small. There is a short water supply range.
Main features
| Model | Yamaha 28 | ||
| Length | 28 ft | ||
| Beam | 9.75 ft | ||
| Draft | 5.92 ft | ||
| Country | Japan (Asia) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 18.06 | ||
| Ballast / displ. | 34.84 % | ||
| Displ. / length | 222.51 | ||
| Comfort ratio | 19.05 | ||
| Capsize | 2.11 |
Hull
| Hull type | Monohull fin keel with spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 23.33 ft | ||
| Maximum draft | 5.92 ft | ||
| Displacement | 6329 lbs | ||
| Ballast | 2205 lbs | ||
| Hull speed | 6.47 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 385 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 0 sq.ft | ?? | |
| Sail area main | 0 sq.ft | ?? | |
| I | 0 ft | ?? | |
| J | 0 ft | ?? | |
| P | 0 ft | ?? | |
| E | 0 ft | ?? |
Engine
| Nb engines | 1 | ||
| Total power | 18 HP | ||
| Fuel capacity | 16 gals |
Accommodations
| Water capacity | 40 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Yamaha | ||
| Designer | Yamaha Design team | ||
| First built | 1980 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
