The Yamaha 26 is a 26.18ft fractional sloop designed by Yamaha Design team and built in fiberglass by Yamaha since 1979.
The Yamaha 26 is a moderate weight sailboat which is a reasonably good performer. It is stable / stiff and has a low righting capability if capsized. It is best suited as a day-boat. The fuel capacity is originally very small. There is a very short water supply range.
Main features
| Model | Yamaha 26 | ||
| Length | 26.18 ft | ||
| Beam | 9.19 ft | ||
| Draft | 5.09 ft | ||
| Country | Japan (Asia) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 17.54 | ||
| Ballast / displ. | 33 % | ||
| Displ. / length | 209.36 | ||
| Comfort ratio | 15.50 | ||
| Capsize | 2.26 |
Hull
| Hull type | Monohull fin keel with spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 21 ft | ||
| Maximum draft | 5.09 ft | ||
| Displacement | 4343 lbs | ||
| Ballast | 1433 lbs | ||
| Hull speed | 6.14 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 291 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 124.01 sq.ft | ||
| Sail area main | 166.47 sq.ft | ||
| I | 28.54 ft | ||
| J | 8.69 ft | ||
| P | 29.86 ft | ||
| E | 11.15 ft |
Engine
| Nb engines | 1 | ||
| Total power | 7.50 HP | ||
| Fuel capacity | 7 gals |
Accommodations
| Water capacity | 18 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Yamaha | ||
| Designer | Yamaha Design team | ||
| First built | 1979 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
