The Yamaha 24 is a 24.33ft masthead sloop designed by Yamaha Design Group and built in fiberglass by Yamaha since 1976.
The Yamaha 24 is a light sailboat which is under powered. It is stable / stiff and has a low righting capability if capsized. It is best suited as a day-boat.
Main features
| Model | Yamaha 24 | ||
| Length | 24.33 ft | ||
| Beam | 8.50 ft | ||
| Draft | 4.50 ft | ||
| Country | Japan (Asia) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 13.70 | ||
| Ballast / displ. | 39.66 % | ||
| Displ. / length | 171.18 | ||
| Comfort ratio | 14.69 | ||
| Capsize | 2.21 |
Hull
| Hull type | Monohull fin keel with spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 21.17 ft | ||
| Maximum draft | 4.50 ft | ||
| Displacement | 3638 lbs | ||
| Ballast | 1443 lbs | ||
| Hull speed | 6.17 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 202 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 100.73 sq.ft | ||
| Sail area main | 101.18 sq.ft | ||
| I | 25.50 ft | ||
| J | 7.90 ft | ||
| P | 21.30 ft | ||
| E | 9.50 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Yamaha | ||
| Designer | Yamaha Design Group | ||
| First built | 1976 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
