The Xl 2 42 allied is a 41.5ft masthead sloop designed by Sparkman & Stephens and built in fiberglass by Allied Boat Company Inc. (USA) between 1969 and 1982.
The Xl 2 42 allied is a heavy sailboat which is a good performer. It is very stable / stiff and has an excellent righting capability if capsized. It is best suited as a bluewater cruising boat. The fuel capacity is originally small. There is a good water supply range.
Main features
| Model | Xl 2 42 allied | ||
| Length | 41.50 ft | ||
| Beam | 11.50 ft | ||
| Draft | 4.17 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 18.38 | ||
| Ballast / displ. | 41.23 % | ||
| Displ. / length | 315.20 | ||
| Comfort ratio | 31.42 | ||
| Capsize | 1.78 |
Hull
| Hull type | Monohull keel with centerboard | ||
| Construction | Fiberglass | ||
| Waterline length | 29 ft | ||
| Maximum draft | 8.33 ft | ||
| Displacement | 17220 lbs | ||
| Ballast | 7100 lbs | ||
| Hull speed | 7.22 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 763 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 396 sq.ft | ||
| Sail area main | 366.56 sq.ft | ||
| I | 48 ft | ||
| J | 16.50 ft | ||
| P | 42.50 ft | ||
| E | 17.25 ft |
Engine
| Nb engines | 1 | ||
| Total power | 40 HP | ||
| Fuel capacity | 30 gals |
Accommodations
| Water capacity | 100 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Allied Boat Company Inc. (USA) | ||
| Designer | Sparkman & Stephens | ||
| First built | 1969 | ||
| Last built | 1982 | ||
| Number built | 0 | ?? |
