The X 46 is a 45.96ft fractional sloop designed by Niels Jeppesen and built in fiberglass by X-Yachts between 2003 and 2010.
75 units have been built.
The X 46 is a light sailboat which is under powered. It is very stable / stiff and has a good righting capability if capsized. It is best suited as a coastal cruiser. The fuel capacity is originally small.
Main features
| Model | X 46 | ||
| Length | 45.96 ft | ||
| Beam | 13.62 ft | ||
| Draft | 7.87 ft | ||
| Country | Denmark (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 0 | ?? | |
| Ballast / displ. | 43.27 % | ||
| Displ. / length | 166.46 | ||
| Comfort ratio | 26.41 | ||
| Capsize | 1.92 |
Hull
| Hull type | Monohull fin Keel with bulb | ||
| Construction | Fiberglass | ||
| Waterline length | 39.47 ft | ||
| Maximum draft | 7.87 ft | ||
| Displacement | 22928 lbs | ||
| Ballast | 9921 lbs | ||
| Hull speed | 8.42 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 0 sq.ft | ?? | |
| Air draft | 0 ft | ?? | |
| Sail area fore | 0 sq.ft | ?? | |
| Sail area main | 0 sq.ft | ?? | |
| I | 0 ft | ?? | |
| J | 0 ft | ?? | |
| P | 0 ft | ?? | |
| E | 0 ft | ?? |
Engine
| Nb engines | 1 | ||
| Total power | 55 HP | ||
| Fuel capacity | 37 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | X-Yachts | ||
| Designer | Niels Jeppesen | ||
| First built | 2003 | ||
| Last built | 2010 | ||
| Number built | 75 |
