The X 35 is a 34.81ft fractional sloop designed by Niels Jeppesen and built in fiberglass by X-Yachts since 2005.
The X 35 is a light sailboat which is a very high performer. It is stable / stiff and has a low righting capability if capsized. It is best suited as a racing boat.
Main features
| Model | X 35 | ||
| Length | 34.81 ft | ||
| Beam | 10.73 ft | ||
| Draft | 7.05 ft | ||
| Country | Denmark (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 25.16 | ||
| Ballast / displ. | 39.54 % | ||
| Displ. / length | 158.01 | ||
| Comfort ratio | 19.79 | ||
| Capsize | 2.03 |
Hull
| Hull type | Monohull fin keel with bulb and spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 29.92 ft | ||
| Maximum draft | 7.05 ft | ||
| Displacement | 9480 lbs | ||
| Ballast | 3748 lbs | ||
| Hull speed | 7.33 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 702 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 326.57 sq.ft | ||
| Sail area main | 375.87 sq.ft | ||
| I | 47.57 ft | ||
| J | 13.73 ft | ||
| P | 46.75 ft | ||
| E | 16.08 ft |
Engine
| Nb engines | 1 | ||
| Total power | 20 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | X-Yachts | ||
| Designer | Niels Jeppesen | ||
| First built | 2005 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
