The X 102 is a 32.92ft fractional sloop designed by Niels Jeppesen and built in fiberglass by X-Yachts between 1981 and 1987.
173 units have been built.
The X 102 is a moderate weight sailboat which is a very high performer. It is very stable / stiff and has a low righting capability if capsized. It is best suited as a racing boat. The fuel capacity is originally very small. There is a very short water supply range.
Main features
| Model | X 102 | ||
| Length | 32.92 ft | ||
| Beam | 11.20 ft | ||
| Draft | 6.20 ft | ||
| Country | Denmark (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 22.10 | ||
| Ballast / displ. | 45.71 % | ||
| Displ. / length | 205.37 | ||
| Comfort ratio | 17.15 | ||
| Capsize | 2.27 |
Hull
| Hull type | Monohull fin keel with spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 25.58 ft | ||
| Maximum draft | 6.20 ft | ||
| Displacement | 7700 lbs | ||
| Ballast | 3520 lbs | ||
| Hull speed | 6.78 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 537 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 217.53 sq.ft | ||
| Sail area main | 319.37 sq.ft | ||
| I | 38.50 ft | ||
| J | 11.30 ft | ||
| P | 42.30 ft | ||
| E | 15.10 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 12 gals |
Accommodations
| Water capacity | 25 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | X-Yachts | ||
| Designer | Niels Jeppesen | ||
| First built | 1981 | ||
| Last built | 1987 | ||
| Number built | 173 |
