The Winner 1120 is a 36.74ft fractional sloop designed by Cees van Tongeren and built in fiberglass by Winner Yachts since 1992.
The Winner 1120 is a moderate weight sailboat which is a good performer. It is very stable / stiff and has a good righting capability if capsized. It is best suited as a coastal cruiser.
Main features
| Model | Winner 1120 | ||
| Length | 36.74 ft | ||
| Beam | 11.81 ft | ||
| Draft | 6.40 ft | ||
| Country | The Nederlands (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 18.19 | ||
| Ballast / displ. | 43.28 % | ||
| Displ. / length | 232.19 | ||
| Comfort ratio | 26.31 | ||
| Capsize | 1.93 |
Hull
| Hull type | Monohull fin keel with bulb and spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 30.51 ft | ||
| Maximum draft | 6.40 ft | ||
| Displacement | 14771 lbs | ||
| Ballast | 6393 lbs | ||
| Hull speed | 7.40 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 682 sq.ft | ||
| Air draft | 56.10 ft | ||
| Sail area fore | 297.85 sq.ft | ||
| Sail area main | 384.20 sq.ft | ||
| I | 44.29 ft | ||
| J | 13.45 ft | ||
| P | 45.93 ft | ||
| E | 16.73 ft |
Engine
| Nb engines | 1 | ||
| Total power | 29 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Winner Yachts | ||
| Designer | Cees van Tongeren | ||
| First built | 1992 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
