The Alajuela 33 is a 33.0ft cutter designed by Raymond Richards and built in fiberglass by Alajuela Yacht Corp. since 1977.
The Alajuela 33 is a moderate weight sailboat which is a reasonably good performer. It is reasonably stable / stiff and has a good righting capability if capsized. It is best suited as a bluewater cruising boat. The fuel capacity is average. There is a short water supply range.
Main features
| Model | Alajuela 33 | ||
| Length | 33 ft | ||
| Beam | 10.67 ft | ||
| Draft | 4.75 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 16.29 | ||
| Ballast / displ. | 34.81 % | ||
| Displ. / length | 289.79 | ||
| Comfort ratio | 30.57 | ||
| Capsize | 1.80 |
Hull
| Hull type | Monohull fin keel with rudder on skeg | ||
| Construction | Fiberglass | ||
| Waterline length | 27.50 ft | ||
| Maximum draft | 4.75 ft | ||
| Displacement | 13500 lbs | ||
| Ballast | 4700 lbs | ||
| Hull speed | 7.03 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Cutter | ||
| Sail area (100%) | 575 sq.ft | ||
| Air draft | 45.58 ft | ||
| Sail area fore | 334.11 sq.ft | ||
| Sail area main | 241.07 sq.ft | ||
| I | 42 ft | ||
| J | 15.91 ft | ||
| P | 36.17 ft | ||
| E | 13.33 ft |
Engine
| Nb engines | 1 | ||
| Total power | 27 HP | ||
| Fuel capacity | 50 gals |
Accommodations
| Water capacity | 75 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Alajuela Yacht Corp. | ||
| Designer | Raymond Richards | ||
| First built | 1977 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
