The Windex 92 is a 30.18ft b&r designed by Bergström & Ridder and built in fiberglass since 1981.
The Windex 92 is a light sailboat which is a reasonably good performer. It is very stable / stiff and has a low righting capability if capsized. It is best suited as a day-boat. The fuel capacity is originally very small. There is a very short water supply range.
Main features
| Model | Windex 92 | ||
| Length | 30.18 ft | ||
| Beam | 10.50 ft | ||
| Draft | 3.54 ft | ||
| Country | ?? | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 17.76 | ||
| Ballast / displ. | 48.34 % | ||
| Displ. / length | 198.10 | ||
| Comfort ratio | 16.97 | ||
| Capsize | 2.24 |
Hull
| Hull type | Monohull keel and centerboard with spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 24.61 ft | ||
| Maximum draft | 6.66 ft | ||
| Displacement | 6614 lbs | ||
| Ballast | 3197 lbs | ||
| Hull speed | 6.65 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | B&R | ||
| Sail area (100%) | 390 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 220.85 sq.ft | ||
| Sail area main | 169.46 sq.ft | ||
| I | 37.40 ft | ||
| J | 11.81 ft | ||
| P | 32.81 ft | ||
| E | 10.33 ft |
Engine
| Nb engines | 1 | ||
| Total power | 15 HP | ||
| Fuel capacity | 11 gals |
Accommodations
| Water capacity | 26 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | ?? | ||
| Designer | Bergström & Ridder | ||
| First built | 1981 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
