The Wilderness 30sx is a 29.75ft fractional sloop designed by Chuck Burns and built in fiberglass by Wilderness Boat Works since 1979.
The Wilderness 30sx is an ultralight sailboat which is a very high performer. It is very stable / stiff and has a low righting capability if capsized. It is best suited as a racing boat. The fuel capacity is originally very small. There is a very short water supply range.
Main features
| Model | Wilderness 30sx | ||
| Length | 29.75 ft | ||
| Beam | 8.75 ft | ||
| Draft | 5.50 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 27.74 | ||
| Ballast / displ. | 45.24 % | ||
| Displ. / length | 87.74 | ||
| Comfort ratio | 12.73 | ||
| Capsize | 2.17 |
Hull
| Hull type | Monohull fin keel with spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 27.75 ft | ||
| Maximum draft | 5.50 ft | ||
| Displacement | 4200 lbs | ||
| Ballast | 1900 lbs | ||
| Hull speed | 7.06 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 450 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 200.22 sq.ft | ||
| Sail area main | 197.40 sq.ft | ||
| I | 34.08 ft | ||
| J | 11.75 ft | ||
| P | 34.33 ft | ||
| E | 11.50 ft |
Engine
| Nb engines | 1 | ||
| Total power | 7 HP | ||
| Fuel capacity | 10 gals |
Accommodations
| Water capacity | 10 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Wilderness Boat Works | ||
| Designer | Chuck Burns | ||
| First built | 1979 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
