The West wind 35 is a 35.07ft masthead sloop designed by Angus Primrose and built in fiberglass since 1975.
The West wind 35 is a moderate weight sailboat which is a reasonably good performer. It is very stable / stiff and has a low righting capability if capsized. It is best suited as a coastal cruiser. The fuel capacity is originally small. There is a short water supply range.
Main features
| Model | West wind 35 | ||
| Length | 35.07 ft | ||
| Beam | 11.45 ft | ||
| Draft | 5.74 ft | ||
| Country | ?? | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 16.76 | ||
| Ballast / displ. | 45.46 % | ||
| Displ. / length | 235.31 | ||
| Comfort ratio | 23.95 | ||
| Capsize | 2 |
Hull
| Hull type | Monohull fin keel with rudder on skeg | ||
| Construction | Fiberglass | ||
| Waterline length | 28.44 ft | ||
| Maximum draft | 5.74 ft | ||
| Displacement | 12125 lbs | ||
| Ballast | 5512 lbs | ||
| Hull speed | 7.15 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 551 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 330.54 sq.ft | ||
| Sail area main | 220.83 sq.ft | ||
| I | 45.28 ft | ||
| J | 14.60 ft | ||
| P | 39.47 ft | ||
| E | 11.19 ft |
Engine
| Nb engines | 1 | ||
| Total power | 28 HP | ||
| Fuel capacity | 40 gals |
Accommodations
| Water capacity | 66 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | ?? | ||
| Designer | Angus Primrose | ||
| First built | 1975 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
