The West indies 38 morgan is a 38.0ft masthead sloop designed by Charles Morgan and built in fiberglass by Heritage Yacht Corp. (USA) since 1976.
The West indies 38 morgan is a moderate weight sailboat which is a reasonably good performer. It is very stable / stiff and has a good righting capability if capsized. It is best suited as a coastal cruiser. The fuel capacity is average. There is a short water supply range.
Main features
| Model | West indies 38 morgan | ||
| Length | 38 ft | ||
| Beam | 12 ft | ||
| Draft | 4 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 16.91 | ||
| Ballast / displ. | 44.12 % | ||
| Displ. / length | 221.08 | ||
| Comfort ratio | 28.11 | ||
| Capsize | 1.87 |
Hull
| Hull type | Monohull long keel | ||
| Construction | Fiberglass | ||
| Waterline length | 32.50 ft | ||
| Maximum draft | 4 ft | ||
| Displacement | 17000 lbs | ||
| Ballast | 7500 lbs | ||
| Hull speed | 7.64 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 696 sq.ft | ||
| Air draft | 54 ft | ||
| Sail area fore | 382.08 sq.ft | ||
| Sail area main | 313.93 sq.ft | ||
| I | 49.30 ft | ||
| J | 15.50 ft | ||
| P | 43.30 ft | ||
| E | 14.50 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 55 gals |
Accommodations
| Water capacity | 55 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Heritage Yacht Corp. (USA) | ||
| Designer | Charles Morgan | ||
| First built | 1976 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
