The Wasa 30 is a 36.09ft fractional sloop designed by Leif Ängermark and built in fiberglass by Wasa Yachts between 1978 and 1983.
62 units have been built.
The Wasa 30 is an ultralight sailboat which is a very high performer. It is very stable / stiff and has an excellent righting capability if capsized. It is best suited as a racing boat.
Main features
| Model | Wasa 30 | ||
| Length | 36.09 ft | ||
| Beam | 7.22 ft | ||
| Draft | 5.90 ft | ||
| Country | Sweden (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 22.15 | ||
| Ballast / displ. | 56.24 % | ||
| Displ. / length | 91.71 | ||
| Comfort ratio | 18.64 | ||
| Capsize | 1.66 |
Hull
| Hull type | Monohull fin keel with spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 29.53 ft | ||
| Maximum draft | 5.90 ft | ||
| Displacement | 5290 lbs | ||
| Ballast | 2975 lbs | ||
| Hull speed | 7.28 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 419 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 211.87 sq.ft | ||
| Sail area main | 206.69 sq.ft | ||
| I | 34.45 ft | ||
| J | 12.30 ft | ||
| P | 39.37 ft | ||
| E | 10.50 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Wasa Yachts | ||
| Designer | Leif Ängermark | ||
| First built | 1978 | ||
| Last built | 1983 | ||
| Number built | 62 |
