The Venture 21 is a 21.0ft cutter designed by Roger MacGregor and built in fiberglass by Macgregor Yacht Corp between 1966 and 1979.
The Venture 21 is a light sailboat which is a high performer. It is reasonably stable / stiff and has a low righting capability if capsized. It is best suited as a day-boat. There is a very short water supply range.
Main features
| Model | Venture 21 | ||
| Length | 21 ft | ||
| Beam | 6.83 ft | ||
| Draft | 1.50 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 21.41 | ||
| Ballast / displ. | 26.67 % | ||
| Displ. / length | 105.76 | ||
| Comfort ratio | 9.31 | ||
| Capsize | 2.39 |
Hull
| Hull type | Monohull swing keel | ||
| Construction | Fiberglass | ||
| Waterline length | 18.50 ft | ||
| Maximum draft | 5.50 ft | ||
| Displacement | 1500 lbs | ||
| Ballast | 400 lbs | ||
| Hull speed | 5.76 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Cutter | ||
| Sail area (100%) | 175 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 92.35 sq.ft | ||
| Sail area main | 106.42 sq.ft | ||
| I | 24.08 ft | ||
| J | 7.67 ft | ||
| P | 21.83 ft | ||
| E | 9.75 ft |
Engine
| Nb engines | 1 | ||
| Total power | 10 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 3 gals | ||
| Headroom | 4 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Macgregor Yacht Corp | ||
| Designer | Roger MacGregor | ||
| First built | 1966 | ||
| Last built | 1979 | ||
| Number built | 0 | ?? |
