The Us 30 is a 29.92ft masthead sloop designed by Douglas Peterson / Daryl Watson and built in fiberglass by Bayliner (Buccaneer/US Yachts) between 1979 and 1983.
The Us 30 is a moderate weight sailboat which is a reasonably good performer. It is very stable / stiff and has a low righting capability if capsized. It is best suited as a day-boat. The fuel capacity is originally small. There is a very short water supply range.
Main features
| Model | Us 30 | ||
| Length | 29.92 ft | ||
| Beam | 10.25 ft | ||
| Draft | 5.58 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 16.71 | ||
| Ballast / displ. | 40.71 % | ||
| Displ. / length | 200 | ||
| Comfort ratio | 18.41 | ||
| Capsize | 2.15 |
Hull
| Hull type | Monohull fin keel with spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 25 ft | ||
| Maximum draft | 5.58 ft | ||
| Displacement | 7000 lbs | ||
| Ballast | 2850 lbs | ||
| Hull speed | 6.70 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 381 sq.ft | ||
| Air draft | 41.83 ft | ||
| Sail area fore | 239.38 sq.ft | ||
| Sail area main | 155.89 sq.ft | ||
| I | 38.86 ft | ||
| J | 12.32 ft | ||
| P | 34 ft | ||
| E | 9.17 ft |
Engine
| Nb engines | 1 | ||
| Total power | 13 HP | ||
| Fuel capacity | 20 gals |
Accommodations
| Water capacity | 29 gals | ||
| Headroom | 6.17 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Bayliner (Buccaneer/US Yachts) | ||
| Designer | Douglas Peterson / Daryl Watson | ||
| First built | 1979 | ||
| Last built | 1983 | ||
| Number built | 0 | ?? |
