Tylercraft 24
The Tylercraft 24 is a 24.0ft masthead sloop designed by Ted Tyler and built in fiberglass by Tylercraft (USA) since 1961.
The Tylercraft 24 is a moderate weight sailboat which is slightly under powered. It is stable / stiff and has a good righting capability if capsized. It is best suited as a coastal cruiser. There is a very short water supply range.
Tylercraft 24 for sale elsewhere on the web:
Main features
| Model | Tylercraft 24 | ||
| Length | 24 ft | ||
| Beam | 7.42 ft | ||
| Draft | 2 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
Login or register to personnalize this screen.
You will be able to pin external links of your choice.
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 15.47 | ||
| Ballast / displ. | 36.25 % | ||
| Displ. / length | 223.21 | ||
| Comfort ratio | 20.19 | ||
| Capsize | 1.87 |
Hull
| Hull type | Monohull twin Keel | ||
| Construction | Fiberglass | ||
| Waterline length | 20 ft | ||
| Maximum draft | 2 ft | ||
| Displacement | 4000 lbs | ||
| Ballast | 1450 lbs | ||
| Hull speed | 5.99 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 243 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 0 sq.ft | ?? | |
| Sail area main | 0 sq.ft | ?? | |
| I | 0 ft | ?? | |
| J | 0 ft | ?? | |
| P | 0 ft | ?? | |
| E | 0 ft | ?? |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 20 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Tylercraft (USA) | ||
| Designer | Ted Tyler | ||
| First built | 1961 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
