The Trintella 47 is a 47.25ft fractional sloop designed by Ron Holland and built in fiberglass by Trintella Yachts between 1996 and 2002.
7 units have been built.
The Trintella 47 is a moderate weight sailboat which is a reasonably good performer. It is reasonably stable / stiff and has a good righting capability if capsized. It is best suited as a bluewater cruising boat. The fuel capacity is excellent. There is an excellent water supply range.
Main features
| Model | Trintella 47 | ||
| Length | 47.25 ft | ||
| Beam | 14.75 ft | ||
| Draft | 6.42 ft | ||
| Country | The Nederlands (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 16.59 | ||
| Ballast / displ. | 32.74 % | ||
| Displ. / length | 277.07 | ||
| Comfort ratio | 35.47 | ||
| Capsize | 1.83 |
Hull
| Hull type | Monohull fin keel with spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 37.83 ft | ||
| Maximum draft | 6.42 ft | ||
| Displacement | 33600 lbs | ||
| Ballast | 11000 lbs | ||
| Hull speed | 8.24 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 1075 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 0 sq.ft | ?? | |
| Sail area main | 0 sq.ft | ?? | |
| I | 0 ft | ?? | |
| J | 0 ft | ?? | |
| P | 0 ft | ?? | |
| E | 0 ft | ?? |
Engine
| Nb engines | 1 | ||
| Total power | 88 HP | ||
| Fuel capacity | 221 gals |
Accommodations
| Water capacity | 260 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Trintella Yachts | ||
| Designer | Ron Holland | ||
| First built | 1996 | ||
| Last built | 2002 | ||
| Number built | 7 |
