The Triangle 32 is a 32.0ft masthead ketch designed by Charles Angle and built in fiberglass by Grampian Marine between 1961 and 1968.
The Triangle 32 is a moderate weight sailboat which is slightly under powered. It is reasonably stable / stiff and has an excellent righting capability if capsized. It is best suited as a bluewater cruising boat. The fuel capacity is originally small. There is a good water supply range.
Main features
| Model | Triangle 32 | ||
| Length | 32 ft | ||
| Beam | 10 ft | ||
| Draft | 3.50 ft | ||
| Country | Canada (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 14.86 | ||
| Ballast / displ. | 25 % | ||
| Displ. / length | 277.38 | ||
| Comfort ratio | 30.43 | ||
| Capsize | 1.75 |
Hull
| Hull type | Monohull keel with centerboard | ||
| Construction | Fiberglass | ||
| Waterline length | 26.83 ft | ||
| Maximum draft | 6 ft | ||
| Displacement | 12000 lbs | ||
| Ballast | 3000 lbs | ||
| Hull speed | 6.94 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Ketch | ||
| Sail area (100%) | 485 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 187 sq.ft | ||
| Sail area main | 198 sq.ft | ||
| I | 34 ft | ||
| J | 11 ft | ||
| P | 30 ft | ||
| E | 13.20 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 36 gals |
Accommodations
| Water capacity | 100 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Grampian Marine | ||
| Designer | Charles Angle | ||
| First built | 1961 | ||
| Last built | 1968 | ||
| Number built | 0 | ?? |
