The Tonic 23 jeanneau is a 23.94ft fractional sloop designed by Philippe Harlé and built in fiberglass by Jeanneau (FRA) between 1985 and 1989.
The Tonic 23 jeanneau is a light sailboat which is a good performer. It is reasonably stable / stiff and has a low righting capability if capsized. It is best suited as a day-boat.
Main features
| Model | Tonic 23 jeanneau | ||
| Length | 23.94 ft | ||
| Beam | 8.20 ft | ||
| Draft | 2.30 ft | ||
| Country | France (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 19.72 | ||
| Ballast / displ. | 34.54 % | ||
| Displ. / length | 152.27 | ||
| Comfort ratio | 12.54 | ||
| Capsize | 2.31 |
Hull
| Hull type | Monohull fin keel with transom hung rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 20.33 ft | ||
| Maximum draft | 2.30 ft | ||
| Displacement | 2866 lbs | ||
| Ballast | 990 lbs | ||
| Hull speed | 6.04 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 248 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 102 sq.ft | ||
| Sail area main | 146.32 sq.ft | ||
| I | 25.92 ft | ||
| J | 7.87 ft | ||
| P | 27.87 ft | ||
| E | 10.50 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Jeanneau (FRA) | ||
| Designer | Philippe Harlé | ||
| First built | 1985 | ||
| Last built | 1989 | ||
| Number built | 0 | ?? |
