The Tomahawk 25 is a 25.33ft masthead sloop designed by Alan Hill and built in fiberglass by Marine Construction Ltd. (UK) since 1970.
300 units have been built.
The Tomahawk 25 is a moderate weight sailboat which is slightly under powered. It is very stable / stiff and has a good righting capability if capsized. It is best suited as a coastal cruiser. There is a very short water supply range.
Main features
| Model | Tomahawk 25 | ||
| Length | 25.33 ft | ||
| Beam | 8.50 ft | ||
| Draft | 4.67 ft | ||
| Country | United Kingdom (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 15.61 | ||
| Ballast / displ. | 43.43 % | ||
| Displ. / length | 282.70 | ||
| Comfort ratio | 20.95 | ||
| Capsize | 1.98 |
Hull
| Hull type | Monohull fin keel with rudder on skeg | ||
| Construction | Fiberglass | ||
| Waterline length | 20 ft | ||
| Maximum draft | 4.67 ft | ||
| Displacement | 5066 lbs | ||
| Ballast | 2200 lbs | ||
| Hull speed | 5.99 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 287 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 155.34 sq.ft | ||
| Sail area main | 114.41 sq.ft | ||
| I | 30.37 ft | ||
| J | 10.23 ft | ||
| P | 25.48 ft | ||
| E | 8.98 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 20 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Marine Construction Ltd. (UK) | ||
| Designer | Alan Hill | ||
| First built | 1970 | ||
| Last built | 0 | ?? | |
| Number built | 300 |
