The Tina carter is a 36.91ft masthead sloop designed by Richard (Dick) Carter and built in fiberglass between 1967 and 1970.
40 units have been built.
The Tina carter is a heavy sailboat which is a reasonably good performer. It is reasonably stable / stiff and has a good righting capability if capsized. It is best suited as a coastal cruiser.
Main features
| Model | Tina carter | ||
| Length | 36.91 ft | ||
| Beam | 10.79 ft | ||
| Draft | 6.17 ft | ||
| Country | ?? | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 17.11 | ||
| Ballast / displ. | 34.04 % | ||
| Displ. / length | 320.10 | ||
| Comfort ratio | 29.74 | ||
| Capsize | 1.81 |
Hull
| Hull type | Monohull fin keel with rudder on skeg | ||
| Construction | Fiberglass | ||
| Waterline length | 26.67 ft | ||
| Maximum draft | 6.17 ft | ||
| Displacement | 13602 lbs | ||
| Ballast | 4630 lbs | ||
| Hull speed | 6.92 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 607 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 0 sq.ft | ?? | |
| Sail area main | 0 sq.ft | ?? | |
| I | 0 ft | ?? | |
| J | 0 ft | ?? | |
| P | 0 ft | ?? | |
| E | 0 ft | ?? |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | ?? | ||
| Designer | Richard (Dick) Carter | ||
| First built | 1967 | ||
| Last built | 1970 | ||
| Number built | 40 |
