The Tartan 41 is a 40.63ft masthead sloop designed by Sparkman & Stephens and built in fiberglass by Tartan Marine between 1972 and 1976.
80 units have been built.
The Tartan 41 is a moderate weight sailboat which is a reasonably good performer. It is very stable / stiff and has a good righting capability if capsized. It is best suited as a coastal cruiser. There is a short water supply range.
Main features
| Model | Tartan 41 | ||
| Length | 40.63 ft | ||
| Beam | 12.25 ft | ||
| Draft | 6.80 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 17.05 | ||
| Ballast / displ. | 51.54 % | ||
| Displ. / length | 228.53 | ||
| Comfort ratio | 27.97 | ||
| Capsize | 1.88 |
Hull
| Hull type | Monohull fin keel with rudder on skeg | ||
| Construction | Fiberglass | ||
| Waterline length | 32.67 ft | ||
| Maximum draft | 6.80 ft | ||
| Displacement | 17850 lbs | ||
| Ballast | 9200 lbs | ||
| Hull speed | 7.66 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 725 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 444.72 sq.ft | ||
| Sail area main | 279.90 sq.ft | ||
| I | 51 ft | ||
| J | 17.44 ft | ||
| P | 45 ft | ||
| E | 12.44 ft |
Engine
| Nb engines | 1 | ||
| Total power | 20 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 60 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Tartan Marine | ||
| Designer | Sparkman & Stephens | ||
| First built | 1972 | ||
| Last built | 1976 | ||
| Number built | 80 |
