The Tartan 37 ss is a 37.29ft masthead sloop designed by Sparkman & Stephens and built in fiberglass by Tartan Marine between 1976 and 1989.
486 units have been built.
The Tartan 37 ss is a moderate weight sailboat which is a reasonably good performer. It is very stable / stiff and has a good righting capability if capsized. It is best suited as a coastal cruiser. The fuel capacity is average. There is a short water supply range.
Main features
| Model | Tartan 37 ss | ||
| Length | 37.29 ft | ||
| Beam | 11.75 ft | ||
| Draft | 4.17 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 16.14 | ||
| Ballast / displ. | 48.39 % | ||
| Displ. / length | 298.92 | ||
| Comfort ratio | 28.91 | ||
| Capsize | 1.89 |
Hull
| Hull type | Monohull keel and centerboard with rudder on skeg | ||
| Construction | Fiberglass | ||
| Waterline length | 28.50 ft | ||
| Maximum draft | 7.75 ft | ||
| Displacement | 15500 lbs | ||
| Ballast | 7500 lbs | ||
| Hull speed | 7.15 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 625 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 376 sq.ft | ||
| Sail area main | 249 sq.ft | ||
| I | 47 ft | ||
| J | 16 ft | ||
| P | 41.50 ft | ||
| E | 12 ft |
Engine
| Nb engines | 1 | ||
| Total power | 41 HP | ||
| Fuel capacity | 50 gals |
Accommodations
| Water capacity | 90 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Tartan Marine | ||
| Designer | Sparkman & Stephens | ||
| First built | 1976 | ||
| Last built | 1989 | ||
| Number built | 486 |
