The Tangent one tartan is a 42.83ft masthead sloop designed by Doug Peterson and built in fiberglass by Tartan Marine since 1982.
The Tangent one tartan is a moderate weight sailboat which is a high performer. It is very stable / stiff and has a good righting capability if capsized. It is best suited as a fast cruiser.
Main features
| Model | Tangent one tartan | ||
| Length | 42.83 ft | ||
| Beam | 12.98 ft | ||
| Draft | 7.92 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 20.54 | ||
| Ballast / displ. | 49.45 % | ||
| Displ. / length | 203.52 | ||
| Comfort ratio | 25.28 | ||
| Capsize | 1.97 |
Hull
| Hull type | Monohull fin keel with spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 34.24 ft | ||
| Maximum draft | 7.92 ft | ||
| Displacement | 18300 lbs | ||
| Ballast | 9050 lbs | ||
| Hull speed | 7.84 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 888 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 512.53 sq.ft | ||
| Sail area main | 375.33 sq.ft | ||
| I | 57.75 ft | ||
| J | 17.75 ft | ||
| P | 51.17 ft | ||
| E | 14.67 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Tartan Marine | ||
| Designer | Doug Peterson | ||
| First built | 1982 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
