The Synergy 1000 is a 32.83ft fractional sloop designed by Carl Schumacher and built in fiberglass since 1999.
10 units have been built.
The Synergy 1000 is an ultralight sailboat which is a very high performer. It is very stable / stiff and has a low righting capability if capsized. It is best suited as a racing boat.
Main features
| Model | Synergy 1000 | ||
| Length | 32.83 ft | ||
| Beam | 9.75 ft | ||
| Draft | 7 ft | ||
| Country | ?? | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 34.59 | ||
| Ballast / displ. | 50.88 % | ||
| Displ. / length | 77.34 | ||
| Comfort ratio | 10.57 | ||
| Capsize | 2.40 |
Hull
| Hull type | Monohull fin keel with bulb and spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 29.17 ft | ||
| Maximum draft | 7 ft | ||
| Displacement | 4300 lbs | ||
| Ballast | 2188 lbs | ||
| Hull speed | 7.24 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 570 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 244.50 sq.ft | ||
| Sail area main | 325.50 sq.ft | ||
| I | 40.75 ft | ||
| J | 12 ft | ||
| P | 42 ft | ||
| E | 15.50 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | ?? | ||
| Designer | Carl Schumacher | ||
| First built | 1999 | ||
| Last built | 0 | ?? | |
| Number built | 10 |
