The Sydney 32 is a 31.67ft fractional sloop designed by Murray Burns Dovell and built in carbon fiber or composite by Sydney Yachts/Bashford Int. since 2003.
The Sydney 32 is a light sailboat which is a very high performer. It is reasonably stable / stiff and has a low righting capability if capsized. It is best suited as a racing boat. The fuel capacity is originally very small. There is a short water supply range.
Main features
| Model | Sydney 32 | ||
| Length | 31.67 ft | ||
| Beam | 10.50 ft | ||
| Draft | 6.67 ft | ||
| Country | Australia | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 24.11 | ||
| Ballast / displ. | 34.83 % | ||
| Displ. / length | 138.98 | ||
| Comfort ratio | 15.84 | ||
| Capsize | 2.22 |
Hull
| Hull type | Monohull fin keel with bulb and spade rudder | ||
| Construction | Carbon fiber or composite | ||
| Waterline length | 28 ft | ||
| Maximum draft | 6.67 ft | ||
| Displacement | 6834 lbs | ||
| Ballast | 2380 lbs | ||
| Hull speed | 7.09 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 541 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 247.17 sq.ft | ||
| Sail area main | 292.99 sq.ft | ||
| I | 40.62 ft | ||
| J | 12.17 ft | ||
| P | 39.70 ft | ||
| E | 14.76 ft |
Engine
| Nb engines | 1 | ||
| Total power | 18 HP | ||
| Fuel capacity | 18 gals |
Accommodations
| Water capacity | 40 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Sydney Yachts/Bashford Int. | ||
| Designer | Murray Burns Dovell | ||
| First built | 2003 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
