The Swing 28 is a 27.49ft fractional sloop designed by Bruce Farr and built in fiberglass since 1987.
The Swing 28 is a light sailboat which is a very high performer. It is reasonably stable / stiff and has a low righting capability if capsized. It is best suited as a racing boat.
Main features
| Model | Swing 28 | ||
| Length | 27.49 ft | ||
| Beam | 9.58 ft | ||
| Draft | 4.96 ft | ||
| Country | ?? | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 22.17 | ||
| Ballast / displ. | 0 % | ||
| Displ. / length | 143.65 | ||
| Comfort ratio | 12.61 | ||
| Capsize | 2.40 |
Hull
| Hull type | Monohull fin keel with spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 23.29 ft | ||
| Maximum draft | 4.96 ft | ||
| Displacement | 4065 lbs | ||
| Ballast | 0 lbs | ||
| Hull speed | 6.47 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 352 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 142.93 sq.ft | ||
| Sail area main | 209.15 sq.ft | ||
| I | 30.25 ft | ||
| J | 9.45 ft | ||
| P | 32.68 ft | ||
| E | 12.80 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | ?? | ||
| Designer | Bruce Farr | ||
| First built | 1987 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
