The Swarbrick 80 is a 26.25ft fractional sloop designed by Kim Swarbrick and built in fiberglass by Swarbrick & Swarbrick since 1978.
The Swarbrick 80 is a light sailboat which is a very high performer. It is stable / stiff and has a low righting capability if capsized. It is best suited as a racing boat.
Main features
| Model | Swarbrick 80 | ||
| Length | 26.25 ft | ||
| Beam | 8.86 ft | ||
| Draft | 4.59 ft | ||
| Country | Australia | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 24.22 | ||
| Ballast / displ. | 39.31 % | ||
| Displ. / length | 109.05 | ||
| Comfort ratio | 10.79 | ||
| Capsize | 2.44 |
Hull
| Hull type | Monohull fin keel with transom hung rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 23.29 ft | ||
| Maximum draft | 4.59 ft | ||
| Displacement | 3086 lbs | ||
| Ballast | 1213 lbs | ||
| Hull speed | 6.47 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 320 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 136.52 sq.ft | ||
| Sail area main | 183.62 sq.ft | ||
| I | 28.71 ft | ||
| J | 9.51 ft | ||
| P | 31.99 ft | ||
| E | 11.48 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Swarbrick & Swarbrick | ||
| Designer | Kim Swarbrick | ||
| First built | 1978 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
