Swan 80 2 fd
The Swan 80 2 fd is a 82.28ft masthead sloop designed by German Frers and built in fiberglass by Nautor (Swan sailboats) between 2010 and 2012.
5 units have been built.
The Swan 80 2 fd is an ultralight sailboat which is a very high performer. It is very stable / stiff and has a good righting capability if capsized. It is best suited as a fast cruiser. The fuel capacity is excellent. There is an excellent water supply range.
Swan 80 2 fd for sale elsewhere on the web:
Main features
| Model | Swan 80 2 fd | ||
| Length | 82.28 ft | ||
| Beam | 19.95 ft | ||
| Draft | 13.12 ft | ||
| Country | Finland (Europe) | ||
| Estimated price | $ 0 | ?? |
Login or register to personnalize this screen.
You will be able to pin external links of your choice.
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 28.90 | ||
| Ballast / displ. | 50.14 % | ||
| Displ. / length | 91.58 | ||
| Comfort ratio | 30.05 | ||
| Capsize | 1.86 |
Hull
| Hull type | Monohull fin keel with bulb and spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 72.80 ft | ||
| Maximum draft | 13.12 ft | ||
| Displacement | 79150 lbs | ||
| Ballast | 39683 lbs | ||
| Hull speed | 11.43 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 3314 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 1618.79 sq.ft | ||
| Sail area main | 1694.94 sq.ft | ||
| I | 104.98 ft | ?? | |
| J | 30.84 ft | ||
| P | 99.41 ft | ||
| E | 34.10 ft |
Engine
| Nb engines | 1 | ||
| Total power | 190 HP | ||
| Fuel capacity | 396 gals |
Accommodations
| Water capacity | 317 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Nautor (Swan sailboats) | ||
| Designer | German Frers | ||
| First built | 2010 | ||
| Last built | 2012 | ||
| Number built | 5 |
Other photos
