Swan 39
The Swan 39 is a 39.3ft masthead sloop designed by Ron Holland and built in fiberglass by Nautor (Swan sailboats) between 1978 and 1980.
33 units have been built.
The Swan 39 is a moderate weight sailboat which is a reasonably good performer. It is very stable / stiff and has a good righting capability if capsized. It is best suited as a coastal cruiser. The fuel capacity is originally small. There is a short water supply range.
Swan 39 for sale elsewhere on the web:
Main features
| Model | Swan 39 | ||
| Length | 39.30 ft | ||
| Beam | 12.50 ft | ||
| Draft | 7.20 ft | ||
| Country | Finland (Europe) | ||
| Estimated price | $ 0 | ?? |
Login or register to personnalize this screen.
You will be able to pin external links of your choice.
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 17.79 | ||
| Ballast / displ. | 43.89 % | ||
| Displ. / length | 257.09 | ||
| Comfort ratio | 28.45 | ||
| Capsize | 1.91 |
Hull
| Hull type | Monohull fin keel with spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 31.50 ft | ||
| Maximum draft | 7.20 ft | ||
| Displacement | 18000 lbs | ||
| Ballast | 7900 lbs | ||
| Hull speed | 7.52 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 761 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 445.50 sq.ft | ||
| Sail area main | 315.88 sq.ft | ||
| I | 54 ft | ||
| J | 16.50 ft | ||
| P | 47.50 ft | ||
| E | 13.30 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 32 gals |
Accommodations
| Water capacity | 80 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Nautor (Swan sailboats) | ||
| Designer | Ron Holland | ||
| First built | 1978 | ||
| Last built | 1980 | ||
| Number built | 33 |
Other photos
