The Supercat 20 is a 20.0ft frac. sloop (rotating spar) designed by Steve Edmunds / Bill Roberts and built in fiberglass by Boston Whaler (USA) since 1980.
The Supercat 20 is an ultralight sailboat which is a very high performer.
Main features
| Model | Supercat 20 | ||
| Length | 20 ft | ||
| Beam | 12 ft | ||
| Draft | 0.50 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 75.03 | ||
| Ballast / displ. | 0 % | ||
| Displ. / length | 29.29 | ||
| Comfort ratio | 1.32 | ||
| Capsize | 6.26 |
Hull
| Hull type | Catamaran twin daggerboard | ||
| Construction | Fiberglass | ||
| Waterline length | 19 ft | ||
| Maximum draft | 3.50 ft | ||
| Displacement | 450 lbs | ||
| Ballast | 0 lbs | ||
| Hull speed | 5.84 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Frac. Sloop (Rotating Spar) | ||
| Sail area (100%) | 275 sq.ft | ||
| Air draft | 33 ft | ||
| Sail area fore | 0 sq.ft | ?? | |
| Sail area main | 0 sq.ft | ?? | |
| I | 0 ft | ?? | |
| J | 0 ft | ?? | |
| P | 0 ft | ?? | |
| E | 0 ft | ?? |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Boston Whaler (USA) | ||
| Designer | Steve Edmunds / Bill Roberts | ||
| First built | 1980 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
