The Sun odyssey 54 ds jeanneau is a 54.92ft masthead sloop designed by Fauroux & Garroni and built in fiberglass by Jeanneau (FRA) since 2004.
The Sun odyssey 54 ds jeanneau is a light sailboat which is a reasonably good performer. It is not stiff and has a good righting capability if capsized. It is best suited as a coastal cruiser. The fuel capacity is good. There is an excellent water supply range.
Main features
| Model | Sun odyssey 54 ds jeanneau | ||
| Length | 54.92 ft | ||
| Beam | 15.92 ft | ||
| Draft | 6.50 ft | ||
| Country | France (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 17.42 | ||
| Ballast / displ. | 29.41 % | ||
| Displ. / length | 146.66 | ||
| Comfort ratio | 28.82 | ||
| Capsize | 1.91 |
Hull
| Hull type | Monohull fin keel with bulb and spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 48.50 ft | ||
| Maximum draft | 6.50 ft | ||
| Displacement | 37479 lbs | ||
| Ballast | 11023 lbs | ||
| Hull speed | 9.33 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 1214 sq.ft | ||
| Air draft | 73.82 ft | ||
| Sail area fore | 639.32 sq.ft | ||
| Sail area main | 574.93 sq.ft | ||
| I | 66.08 ft | ||
| J | 19.35 ft | ||
| P | 59.92 ft | ||
| E | 19.19 ft |
Engine
| Nb engines | 1 | ||
| Total power | 100 HP | ||
| Fuel capacity | 191 gals |
Accommodations
| Water capacity | 246 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Jeanneau (FRA) | ||
| Designer | Fauroux & Garroni | ||
| First built | 2004 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
