The Sun fizz 40 jeanneau is a 40.35ft masthead sloop designed by Philippe Briand and built in fiberglass by Jeanneau (FRA) between 1980 and 1984.
The Sun fizz 40 jeanneau is a light sailboat which is a reasonably good performer. It is very stable / stiff and has a low righting capability if capsized. It is best suited as a coastal cruiser.
Main features
| Model | Sun fizz 40 jeanneau | ||
| Length | 40.35 ft | ||
| Beam | 12.63 ft | ||
| Draft | 6.40 ft | ||
| Country | France (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 16.85 | ||
| Ballast / displ. | 41.06 % | ||
| Displ. / length | 191.18 | ||
| Comfort ratio | 23.89 | ||
| Capsize | 2 |
Hull
| Hull type | Monohull fin keel with spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 33.50 ft | ||
| Maximum draft | 6.40 ft | ||
| Displacement | 16100 lbs | ||
| Ballast | 6610 lbs | ||
| Hull speed | 7.76 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 669 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 347.50 sq.ft | ||
| Sail area main | 321.75 sq.ft | ||
| I | 50 ft | ||
| J | 13.90 ft | ||
| P | 45 ft | ||
| E | 14.30 ft |
Engine
| Nb engines | 1 | ||
| Total power | 50 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Jeanneau (FRA) | ||
| Designer | Philippe Briand | ||
| First built | 1980 | ||
| Last built | 1984 | ||
| Number built | 0 | ?? |
