The Sun fast 403 jeanneau is a 40.03ft fractional sloop designed by Daniel Andrieu and built in fiberglass by Jeanneau (FRA) since 2004.
The Sun fast 403 jeanneau is a moderate weight sailboat which is a reasonably good performer. It is reasonably stable / stiff and has a good righting capability if capsized. It is best suited as a coastal cruiser. The fuel capacity is originally small. There is a short water supply range.
Main features
| Model | Sun fast 403 jeanneau | ||
| Length | 40.03 ft | ||
| Beam | 12.96 ft | ||
| Draft | 6.89 ft | ||
| Country | France (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 17.31 | ||
| Ballast / displ. | 29.30 % | ||
| Displ. / length | 216.92 | ||
| Comfort ratio | 26.02 | ||
| Capsize | 1.98 |
Hull
| Hull type | Monohull fin keel with bulb and spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 33.37 ft | ||
| Maximum draft | 6.89 ft | ||
| Displacement | 18056 lbs | ||
| Ballast | 5291 lbs | ||
| Hull speed | 7.74 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 742 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 352.57 sq.ft | ||
| Sail area main | 389.73 sq.ft | ||
| I | 50.95 ft | ||
| J | 13.84 ft | ||
| P | 46.59 ft | ||
| E | 16.73 ft |
Engine
| Nb engines | 1 | ||
| Total power | 56 HP | ||
| Fuel capacity | 36 gals |
Accommodations
| Water capacity | 90 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Jeanneau (FRA) | ||
| Designer | Daniel Andrieu | ||
| First built | 2004 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
