Stiletto 30
The Stiletto 30 is a 29.33ft frac. sloop (rotating spar) designed by Peter Wormwood and built in fiberglass with kevlar by Stiletto Catamarans (Force Engineering) since 1982.
The Stiletto 30 is an ultralight sailboat which is a very high performer.
See all sailboats built by Stiletto Catamarans (Force Engineering)
Stiletto 30 for sale elsewhere on the web:
Main features
| Model | Stiletto 30 | ||
| Length | 29.33 ft | ||
| Beam | 17.83 ft | ||
| Draft | 0.90 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
Login or register to personnalize this screen.
You will be able to pin external links of your choice.
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 39.12 | ||
| Ballast / displ. | 0 % | ||
| Displ. / length | 48.54 | ||
| Comfort ratio | 2.54 | ||
| Capsize | 5.57 |
Hull
| Hull type | Catamaran twin daggerboard | ||
| Construction | Fiberglass with kevlar | ||
| Waterline length | 26.83 ft | ||
| Maximum draft | 4 ft | ||
| Displacement | 2100 lbs | ||
| Ballast | 0 lbs | ||
| Hull speed | 6.94 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Frac. Sloop (Rotating Spar) | ||
| Sail area (100%) | 400 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 0 sq.ft | ?? | |
| Sail area main | 0 sq.ft | ?? | |
| I | 0 ft | ?? | |
| J | 0 ft | ?? | |
| P | 0 ft | ?? | |
| E | 0 ft | ?? |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Stiletto Catamarans (Force Engineering) | ||
| Designer | Peter Wormwood | ||
| First built | 1982 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
Other photos
