The Standfast 36 is a 36.0ft masthead sloop designed by Franz Maas and built in fiberglass by Standfast Yachts since 1973.
The Standfast 36 is a heavy sailboat which is slightly under powered. It is very stable / stiff and has a good righting capability if capsized. It is best suited as a bluewater cruising boat. The fuel capacity is originally small. There is a short water supply range.
Main features
| Model | Standfast 36 | ||
| Length | 36 ft | ||
| Beam | 12.33 ft | ||
| Draft | 6.75 ft | ||
| Country | The Nederlands (Europe) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 15.30 | ||
| Ballast / displ. | 40.70 % | ||
| Displ. / length | 314.84 | ||
| Comfort ratio | 30.12 | ||
| Capsize | 1.91 |
Hull
| Hull type | Monohull fin keel with rudder on skeg | ||
| Construction | Fiberglass | ||
| Waterline length | 29 ft | ||
| Maximum draft | 6.75 ft | ||
| Displacement | 17200 lbs | ||
| Ballast | 7000 lbs | ||
| Hull speed | 7.22 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 635 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 376.53 sq.ft | ||
| Sail area main | 258 sq.ft | ||
| I | 48.90 ft | ||
| J | 15.40 ft | ||
| P | 43 ft | ||
| E | 12 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 25 gals |
Accommodations
| Water capacity | 83 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Standfast Yachts | ||
| Designer | Franz Maas | ||
| First built | 1973 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
