The Stag 29 is a 29.2ft fractional sloop designed by Luca Taddei and built in fiberglass between 1984 and 1989.
The Stag 29 is a light sailboat which is a very high performer. It is very stable / stiff and has a low righting capability if capsized. It is best suited as a day-boat. The fuel capacity is originally very small. There is a very short water supply range.
Main features
| Model | Stag 29 | ||
| Length | 29.20 ft | ||
| Beam | 9.84 ft | ||
| Draft | 5.74 ft | ||
| Country | ?? | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 24.58 | ||
| Ballast / displ. | 41.40 % | ||
| Displ. / length | 169.86 | ||
| Comfort ratio | 9.66 | ||
| Capsize | 2.74 |
Hull
| Hull type | Monohull fin keel with spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 19.85 ft | ||
| Maximum draft | 5.74 ft | ||
| Displacement | 2976 lbs | ||
| Ballast | 1232 lbs | ||
| Hull speed | 5.97 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 317 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 133.18 sq.ft | ||
| Sail area main | 183.49 sq.ft | ||
| I | 29.53 ft | ||
| J | 9.02 ft | ||
| P | 31.50 ft | ||
| E | 11.65 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 13 gals |
Accommodations
| Water capacity | 32 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | ?? | ||
| Designer | Luca Taddei | ||
| First built | 1984 | ||
| Last built | 1989 | ||
| Number built | 0 | ?? |
