The Spaulding 33 is a 33.25ft fractional sloop designed by Myron Spaulding and built in wood single chine by Spaulding Boat Works between 1941 and 1968.
9 units have been built.
The Spaulding 33 is a heavy sailboat which is under powered. It is not stiff and has an excellent righting capability if capsized. It is best suited as a bluewater cruising boat.
Main features
| Model | Spaulding 33 | ||
| Length | 33.25 ft | ||
| Beam | 9 ft | ||
| Draft | 5.33 ft | ||
| Country | ?? | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 13.67 | ||
| Ballast / displ. | 0 % | ||
| Displ. / length | 367.84 | ||
| Comfort ratio | 36.09 | ||
| Capsize | 1.59 |
Hull
| Hull type | Monohull fin keel | ||
| Construction | Wood single chine | ||
| Waterline length | 24.25 ft | ||
| Maximum draft | 5.33 ft | ||
| Displacement | 11750 lbs | ||
| Ballast | 0 lbs | ||
| Hull speed | 6.60 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 440 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 154 sq.ft | ||
| Sail area main | 314.50 sq.ft | ||
| I | 28 ft | ||
| J | 11 ft | ||
| P | 37 ft | ||
| E | 17 ft |
Engine
| Nb engines | 1 | ||
| Total power | 0 HP | ||
| Fuel capacity | 0 gals |
Accommodations
| Water capacity | 0 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Spaulding Boat Works | ||
| Designer | Myron Spaulding | ||
| First built | 1941 | ||
| Last built | 1968 | ||
| Number built | 9 |
