The Sparkman stephens 30 2012 is a 30.5ft fractional sloop designed by Sparkman & Stephens/Daniela Abbott and built in fiberglass since 2012.
The Sparkman stephens 30 2012 is a light sailboat which is a very high performer. It is very stable / stiff and has a good righting capability if capsized. It is best suited as a racing boat. The fuel capacity is originally very small. There is a very short water supply range.
Main features
| Model | Sparkman stephens 30 2012 | ||
| Length | 30.50 ft | ||
| Beam | 8.25 ft | ||
| Draft | 5.50 ft | ||
| Country | ?? | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 23.30 | ||
| Ballast / displ. | 42.55 % | ||
| Displ. / length | 121.07 | ||
| Comfort ratio | 18.46 | ||
| Capsize | 1.86 |
Hull
| Hull type | Monohull fin keel with bulb and spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 27.50 ft | ||
| Maximum draft | 5.50 ft | ||
| Displacement | 5640 lbs | ||
| Ballast | 2400 lbs | ||
| Hull speed | 7.03 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 460 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 0 sq.ft | ?? | |
| Sail area main | 0 sq.ft | ?? | |
| I | 0 ft | ?? | |
| J | 0 ft | ?? | |
| P | 0 ft | ?? | |
| E | 0 ft | ?? |
Engine
| Nb engines | 1 | ||
| Total power | 14 HP | ||
| Fuel capacity | 12 gals |
Accommodations
| Water capacity | 13 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | ?? | ||
| Designer | Sparkman & Stephens/Daniela Abbott | ||
| First built | 2012 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
