Sp cruiser island packet
The Sp cruiser island packet is a 41.08ft masthead sloop designed by Bob Johnson and built in fiberglass by Island Packet Yachts since 2007.
The Sp cruiser island packet is a light sailboat which is slightly under powered. It is reasonably stable / stiff and has a good righting capability if capsized. It is best suited as a coastal cruiser. The fuel capacity is excellent. There is a good water supply range.
Sp cruiser island packet for sale elsewhere on the web:
Main features
| Model | Sp cruiser island packet | ||
| Length | 41.08 ft | ||
| Beam | 12.75 ft | ||
| Draft | 3.33 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
Login or register to personnalize this screen.
You will be able to pin external links of your choice.
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 14.18 | ||
| Ballast / displ. | 21.74 % | ||
| Displ. / length | 163.48 | ||
| Comfort ratio | 29.84 | ||
| Capsize | 1.80 |
Hull
| Hull type | Monohull long keel with rudder on skeg | ||
| Construction | Fiberglass | ||
| Waterline length | 39.75 ft | ||
| Maximum draft | 3.33 ft | ||
| Displacement | 23000 lbs | ||
| Ballast | 5000 lbs | ||
| Hull speed | 8.45 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Masthead Sloop | ||
| Sail area (100%) | 714 sq.ft | ||
| Air draft | 55 ft | ||
| Sail area fore | 400.09 sq.ft | ||
| Sail area main | 336.85 sq.ft | ||
| I | 54.25 ft | ||
| J | 14.75 ft | ||
| P | 40.83 ft | ||
| E | 16.50 ft |
Engine
| Nb engines | 1 | ||
| Total power | 110 HP | ||
| Fuel capacity | 220 gals |
Accommodations
| Water capacity | 130 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Island Packet Yachts | ||
| Designer | Bob Johnson | ||
| First built | 2007 | ||
| Last built | 0 | ?? | |
| Number built | 0 | ?? |
