The Soverel 39 is a 38.42ft fractional sloop designed by Mark Soverel and built in fiberglass by Soverel Marine (USA) between 1984 and 1988.
The Soverel 39 is a light sailboat which is a very high performer. It is very stable / stiff and has a low righting capability if capsized. It is best suited as a racing boat. The fuel capacity is originally very small. There is a very short water supply range.
Main features
| Model | Soverel 39 | ||
| Length | 38.42 ft | ||
| Beam | 12.50 ft | ||
| Draft | 7.67 ft | ||
| Country | United states (North America) | ||
| Estimated price | $ 0 | ?? |
See how Sailboatlab works in video
Ratios
| Sail area / displ. | 23.57 | ||
| Ballast / displ. | 55.16 % | ||
| Displ. / length | 125.36 | ||
| Comfort ratio | 17.58 | ||
| Capsize | 2.20 |
Hull
| Hull type | Monohull fin keel with spade rudder | ||
| Construction | Fiberglass | ||
| Waterline length | 34.75 ft | ||
| Maximum draft | 7.67 ft | ||
| Displacement | 11783 lbs | ||
| Ballast | 6500 lbs | ||
| Hull speed | 7.90 knots |
We help you build your own hydraulic steering system - Lecomble & Schmitt
Rigging
| Rigging | Fractional Sloop | ||
| Sail area (100%) | 760 sq.ft | ||
| Air draft | 0 ft | ?? | |
| Sail area fore | 376.13 sq.ft | ||
| Sail area main | 367.50 sq.ft | ||
| I | 51 ft | ||
| J | 14.75 ft | ||
| P | 49 ft | ||
| E | 15 ft |
Engine
| Nb engines | 1 | ||
| Total power | 27 HP | ||
| Fuel capacity | 15 gals |
Accommodations
| Water capacity | 25 gals | ||
| Headroom | 0 ft | ||
| Nb of cabins | 0 | ||
| Nb of berths | 0 | ||
| Nb heads | 0 |
Builder data
| Builder | Soverel Marine (USA) | ||
| Designer | Mark Soverel | ||
| First built | 1984 | ||
| Last built | 1988 | ||
| Number built | 0 | ?? |
